A complete system including a new 6" HBR-6 Rerip, Double bin, conveyors (infeed, waste, outfeed).

Bin Conveyor:  This is a double bin with live bottom.  Each half of the bin has it's own independent drive with conveyor belts in the bottom of the box.  Our intent here was to be able to dump 4/4 in one side and 6/4 in the other side which would give some surge to work back and forth.  Bin dimensions are 10' wide x 8' deep x 4' high.  Side height could be increased depending on the situation.

Operator platform and infeed Conveyors:  There is a guarded operator platform where the operator stands to control the system and feed the Rerip.  The operator controls the Bin Conveyors which then dump into another horizontal transfer conveyor to feed blocks to the front of the Rerip.

Waste Conveyors:  There is a waste conveyor that Rerip edgings fall into and then transfer into a 2nd waste conveyor to remove the waste away from the system.

Outfeed Conveyors:  There are 6 trough conveyors feeding out of the Rerip that drop off in 6' increments as you move away from the Rerip.  This was elevated and designed to have boxes under the drops for the blocks to fall into.

Everything has been wired and is functional.

• Price: $ 108,000         FOB:  Oregon
